A P P E N D I X B
Remotely managing your system through an RS-232 serial interface
74 smarttech.com/kb/170401
get red red=[current] no
set green [target] green=[current] no
get green green=[current] no
set blue [target] blue=[current] no
get blue blue=[current] no
set cyan [target] cyan =[current] no
get cyan cyan =[current] no
set magenta [target] magenta =[current] no
get magenta magenta =[current] no
set yellow [target] yellow =[current] no
get yellow yellow =[current] no
set videofreeze [target] videofreeze =[current] no
get videofreeze videofreeze =[current] no
set displayhide displayhide = [target] no
get displayhide displayhide = [target] no
Field definitions
Field Possible values Description
target displaymode l = SMART
Presentation
l = Bright room
l = Dark room
l = sRGB
l = User
The ranges must match the OSD ranges
current displaymode l SMART
Presentation
l Bright room
l Dark room
l sRGB
l User
The ranges must match the OSD ranges
