User manual

C H A P T E R 4
Integrating other devices
32 smarttech.com/kb/170401
N O T E
Your projector is HD Ready. Its native resolution supports a pixel-perfect display of 720p source
content. However, because the projector compresses 1080p source content to fit its native
resolution, it doesn’t support a pixel-perfect display of 1080p source content.
Video system signal compatibility
The following tables list the projectors’ video system signal compatibility, particularly for signals
delivered over S-Video and Composite video connectors, which the projector adjusts automatically
when you use the aspect ratio commands described in Adjusting projector settings on page 14.
N O T E
The 16:9 command delivers all video modes with black bands along the top and bottom edges of
the screen. The Match Input command might deliver video modes with black bands along the top
and bottom edges of the screen, depending on the input resolution.
SMARTUF70 projector
Video mode Aspect ratio Horizontal
frequency (kHz)
Vertical
frequency (Hz)
Color signal
(MHz)
NTSC 4:3 15.73 29.96 3.58
PAL 4:3 15.62 25 4.43
SECAM 4:3 15.62 25 4.25 (f
ob
)
4.06 (f
or
)
SMARTUF70w projector
Video mode Aspect ratio Horizontal
frequency (kHz)
Vertical
frequency (Hz)
Color signal
(MHz)
NTSC 4:3 15.73 59.94 3.58
PAL 4:3 15.63 50 4.43
SECAM 4:3 15.63 50 4.25 and 4.41
PAL-M 4:3 15.73 59.94 3.58
PAL-N 4:3 15.63 50 3.58
PAL-60 4:3 15.73 59.94 4.43
NTSC 4.43 4:3 15.73 59.94 4.43
