User manual

C H A P T E R 4
Integrating other devices
31 smarttech.com/kb/170401
HD and SD signal format compatibility
The following tables list the projectors’ high definition (HD)and standard definition (SD) format signal
compatibility, which the projector adjusts automatically when you use the aspect ratio commands
described in Adjusting projector settings on page 14.
SMARTUF70 projector
Signal format Aspect ratio Horizontal
frequency (kHz)
Vertical
frequency (Hz)
Match Input
appearance
480i (DVD player)
(640 × 480)
4:3 15.73 59.94 Full screen
567i (DVD player)
(720 × 576)
5:4 15.63 50 Letterbox
720p 16:9 44.96 59.94 Letterbox
720p 16:9 35 50 Letterbox
1080i 16:9 33.7 59.94 Letterbox
1080i 16:9 28.1 50 Letterbox
SMARTUF70w projector
Signal format Aspect
ratio
Horizontal
frequency
(kHz)
Vertical
frequency
(Hz)
Match Input
appearance
(16:10 aspect
ratio mode)
Match Input
appearance
(16:9 aspect
ratio mode)
480i (525i) 4:3 15.73 59.94 Pillarbox Pillarbox
480p (525p) 4:3 31.47 59.94 Pillarbox Pillarbox
576i (625i) 5:4 15.63 50 Pillarbox Pillarbox
576p (625p) 5:4 31.25 50 Pillarbox Pillarbox
720p (750p) 16:9 45 59.94 Letterbox Full screen
720p (750p) 16:9 37.5 50 Letterbox Full screen
1080i (1125i) 16:9 33.75 59.94 Letterbox Full screen
1080i (1125i) 16:9 28.13 50 Letterbox Full screen
1080p (1125p) 16:9 67.5 59.94 Letterbox Full screen
1080p (1125p) 16:9 56.25 50 Letterbox Full screen
