C H A P T E R 4
Integrating other devices
29 smarttech.com/kb/170401
Resolution Mode Aspect ratio Refresh rate (Hz) Match Input
appearance
1280 × 768 SXGA1 75 1.67:1 60 Letterbox
1280 × 800 WXGA 16:10 60 Letterbox
1280 × 960 Quad VGA 60 4:3 60 Full screen
1280 × 960 Quad VGA 85 4:3 85.002 Full screen
1280 × 1024 SXGA3 60 5:4 60.02 Letterbox
1280 × 1024 SXGA3 75 5:4 75.025 Letterbox
1280 × 1024 SXGA3 85 5:4 85.024 Letterbox
1360 x 765 1.04M9 16:9 59.799 Letterbox
1600 x 900 1.44M9 16:9 59.946 Letterbox
1600 × 1200 UXGA 4:3 60 Full screen
1680 x 1050 1680x1050 50 16:10 49.974 Letterbox
1680 x 1050 1680x1050 50 16:10 59.954 Letterbox
1920 x 1080 HD 1080 16:9 60 Letterbox
SMARTUF70w projector
Resolution Mode Aspect
ratio
Refresh
rate (Hz)
Match Input
appearance
(16:10 aspect
ratio mode)
Match Input
appearance
(16:9 aspect
ratio mode)
720 × 400 720×400_85 9:5 85.039 Letterbox Letterbox
640 × 480 VGA 60 4:3 59.94 Pillarbox Pillarbox
800 × 600 VGA 72 4:3 72.809 Pillarbox Pillarbox
800 × 600 VGA 75 4:3 75 Pillarbox Pillarbox
800 × 600 VGA 85 4:3 85.008 Pillarbox Pillarbox
800 × 600 SVGA 56 4:3 56.25 Pillarbox Pillarbox
800 × 600 SVGA 60 4:3 60.317 Pillarbox Pillarbox
800 × 600 SVGA 72 4:3 72.188 Pillarbox Pillarbox
800 × 600 SVGA 75 4:3 75 Pillarbox Pillarbox
800 × 600 SVGA 85 4:3 85.061 Pillarbox Pillarbox
