Chapter 4
27 smarttech.com/kb/170401
Appendix 4: Integrating other devices
Video format compatibility 27
Native video format 27
Video format compatibility 28
SMARTUF70 projector 28
SMARTUF70w projector 29
HD and SD signal format compatibility 31
SMARTUF70 projector 31
SMARTUF70w projector 31
Video system signal compatibility 32
SMARTUF70 projector 32
SMARTUF70w projector 32
Connecting peripheral sources and outputs 33
This appendix provides information on integrating your SMARTBoard800i6 interactive whiteboard
system with peripheral devices.
Video format compatibility
Your projector has a native video format and various video format compatibility modes. You can
change image appearances for certain formats and compatibilities.
Native video format
The following table lists the native VESA RGB video formats for the projector.
Projector Resolution Mode Aspect
ratio
Refresh rate
(Hz)
Horizontal
frequency
(kHz)
Pixel clock
(MHz)
SMARTUF70 1024 × 768 XGA 4:3 60 48 63.5
SMARTUF70w
(16:10 aspect ratio
mode)
1280 × 800 WXGA 16:10 60 48 83.5
