C H A P T E R 3
Using your interactive whiteboard system
16 smarttech.com/kb/170401
Setting Use Notes
Projector Functions menu
Auto Signal
Detect
Enables or disables signal
searching of input connectors.
The default is off.
Select On to have the projector continuously
switch inputs until it finds an active video
source.
Select Off to maintain signal detection in one
input.
Lamp Reminder Turns the lamp replacement
reminder on or off.
This reminder appears 100 hours before the
recommended lamp replacement.
Lamp Mode Adjusts lamp brightness to
Standard or Economy.
Standard displays a high-quality, bright
image.
Economy increases the lamp life by
decreasing the brightness of the image.
Auto Power Off
(minutes)
Sets the length of the auto
power-off countdown timer
between 1 and 240 minutes.
The default is 120 minutes.
The timer begins to count down when the
projector no longer receives a video signal.
The timer finishes when the projector enters
Standby mode.
Select 0 to turn off the timer.
Zoom Adjusts the zoom to the center
of the image in or out from 0 to
30.
The default is 0.
Zooming in cuts off the outer edges of the
source video.
Keystone Adjustment to the size of the
top and bottom edge
Ensure that the top and bottom edges of the
image are horizontal before you position the
left and right edges of the image relative to
your interactive whiteboard.
USB 1 source Enables touch for the selected
video source VGA out,USB 2
will disabled by associating the
video source with the room
computer USB receptacle
(USB1) on the ECP.
The default is VGA out. When the user
switches to the video source the interactive
whiteboard recognizes touch from the device
connected to the room computer USB
receptacle on the ECP. Selecting Disabled
disables the room computer USB receptacle
on the ECP.
USB 2 source Enables touch for the selected
video source HDMI, USB 1 will
be disabled by associating the
video source with the guest
computer USB receptacle
(USB2) on the ECP.
The default is HDMI. When the user switches
to the video source the interactive whiteboard
recognizes touch from the device connected to
the guest computer USB receptacle on the
ECP. Selecting Disabled disables the room
computer USB receptacle on the ECP.
