Chapter 2
7 smarttech.com/kb/170401
Chapter 2: Installing your interactive
whiteboard system
Choosing a location 8
Choosing a height 8
Securing your interactive whiteboard system 9
Locking the pen tray to your interactive whiteboard 9
Securing the projector to the boom 9
Routing the cables 9
Installing SMART software 10
Consult the SMARTBoard800i6 interactive whiteboard system installation document included with
your product for instructions on how to install and secure your system.
I M P O R T A N T
Use the SMARTBoard 800i6-SMP interactive whiteboard system installation guide
(smarttech.com/kb/157703) and the SMARTBoard 800i6-SMP interactive whiteboard system
quick installation guide (smarttech.com/kb/170TBA) to install your interactive whiteboard system.
This chapter provides additional considerations and details for installing your interactive whiteboard
system.
