User manual
Table Of Contents
- Contents
- Important information
- Chapter 1: About your interactive whiteboard system
- Chapter 2: Installing your interactive whiteboard system
- Chapter 3: Using your interactive whiteboard system
- Appendix 4: Integrating other devices
- Chapter 5: Maintaining your interactive whiteboard system
- Chapter 6: Troubleshooting your interactive whiteboard system
- Before you start
- Determining your interactive whiteboard system’s status
- Resolving interactive whiteboard issues
- Resolving projector issues
- Resolving ECP issues
- Accessing the service menu
- Transporting your interactive whiteboard system
- Appendix A: Remotely managing your system through a network interface
- Appendix B: Remotely managing your system through an RS-232 serial interface
- Connecting your room control system to the ECP
- Projector programming commands
- Appendix C: Remote control code definitions
- Appendix D: Hardware environmental compliance
- Index
Chapter 1
1 smarttech.com/kb/170401
Chapter 1: About your interactive
whiteboard system
SMARTBoard800i6 interactive whiteboard system features 2
SMARTBoard 800 series interactive whiteboard 2
SMARTUF70 or SMARTUF70w projector 3
Extended Control Panel (ECP) 4
Included accessories 4
Remote control 4
Pens 4
Eraser 5
VGA connection kit 5
SMARTBoard800i6 interactive whiteboard system accessories 5
RCA connector pod 5
Your SMARTBoard800i6 interactive whiteboard system combines the following components:
l SMARTBoard 800 series interactive whiteboard
l Wall-mounted, short-throw SMARTUF70 or SMARTUF70w projector
l Accessories and optional equipment
This chapter describes the features of your interactive whiteboard and provides information about
product parts and accessories.
