Instruction Manual

9
25%50%75%100%
0 ~ 25%: 4 LED indicator
26% ~ 50%: 3 and 4 LEDs indicator
51% ~ 75% 2 , 3 , and 4 LEDs indicator
76% ~ 100%: All of four LED indicators will illuminate
u
u
u
u
th
rd th
nd rd th
Indicator Condition -
3. SYSTEM DESCRIPTION
l
Battery Level Indicator:
There are four LED bar graphic to indicate the amount of battery capacity
remaining. The higher the battery capacity, the more LED indicators that will
be illuminated. Each LED indicator designates a 25% capacity level. Please
see the following capacity level respectively.
Condition Alarm
Utility Mode
(AC Mode)
Line LED Lighting
Backup Mode
(Power Failure)
Flashing every four seconds
Site fault LED lighting (For 120VAC Models)Site Fault
4 segment LED bar:
0~25%: 4
th
LED lighting; 26~50%: 3
rd
and 4
th
LEDs lighting; 51~75%: 2
nd
,3
rd
, and 4
th
LEDs
lighting; 76~100%: all of 4 LEDs lighting
UPS Fault Fault LED lighting
Overload Overload LED lighting
Low Battery Battery LED flashing every second
Audible Alarm Condition
Condition Alarm
Backup Mode
(Power Failure)
Sounding every four seconds
Low Battery Sounding every second
UPS Fault Continuously Sounding
Overload Sounding every second
Battery Replacement Sounding every second
