4 Determining the Installation Location
4.1 Requirements
Observe the following ambient conditions for the repeater's installation location.
• Protect the repeater from dust, wet conditions, corrosive substances and vapors.
• The repeater requires a 120 V wall socket for the power supply.
• The ambient temperature must be between 32 °F and 131 °F.
4.2 Handling the Antenna
With the Sunny Beam Repeater's adjustable antenna, you can adjust the alignment of
the antenna to suit the local conditions.
From the vertical position, the Sunny
Beam Repeater's antenna can be
rotated a maximum of 180 degrees to
the front or to the bottom. From the
horizontal position, the Sunny Beam's
antenna can also be tilted to the left in
two steps of 45 degrees, as illustrated
to the right.
The antenna may be rotated a maximum of 90 degrees to the front or to
the rear. Further rotation damages the cable.
