Instruction Manual

4 Table of Contents
TABLE OF CONTENTS
SAFETY INSTRUCTIONS 2
PM8 Main Features and Foreword 3
1. INTRODUCTION 5
2. THE DESIGN 5
2.1 High quality components and design
2.2 Inputs and outputs
3. INSTALLATION 5
3.1 What’s included in the box 5
3.2 Rack-mount installation 5
3.3 Mains Voltage & front panel power switch 6
Mains Voltage 6
Power on/off switch & LED power indicator 6
3.4 Audio Connections 7
Analog Inputs – Combo, Input Link 25pin D-sub 7
Analog outputs – Passive Output, Master 1, Master 2 7
4. FRONT PANEL CONTROLS & INDICATORS 8
4.1 Independent (8x) rotary volume attenuation controls 8
4.2 Independent (8x) LED enabled mute switches 8
4.3 Independent (8x) rotary pan controls 8
4.4 Master 1 & 2 volume attenuator controls 8
5. APPLICATION 8
5.1 General use of the PM8 8
6. SPECIFICATIONS 10
Inputs 10
Outputs 10
Power 10
7. WARRANTY 11
7.1 Warranty card and/or website registration 11
7.2 Warranty 11
7.3 How to request a return authorization number 11
7.4 Warranty regulations 12
7.5 Transferability 12
7.6 Damage claims 12
7.7 Other warranty rights 12
