Datasheet

MSTF 2

Plugs

2 mm system

Product MSTF 2

description Spring-loaded 2 mm plug, for leads up to 0.5 mm² and a maximum outer

diameter of 2 mm, suitable to all unsprung 2 mm connections.

article-no. /

*colour

9384201xx

00 01 02 03 04 06 07

black red blue yellow green gray white

drawing

technical data

connection solder connection

rated voltage

(1)

30 VAC / 60 VDC

measurement cat. acc. to IEC 61010 O

(3)

rated current

(1)

(consider derating curve)

6 A

material plug brass, nickel plated

housing material PVC-P

temperature range acc. To IEC61010

(2)

-15 °C to +70 °C

standard IEC 61010

(1)

for normal environmental conditions -5°C to +40°C

(2)

contact the manufacturer for applications at deviating temperature ranges

(3)

Other circuits that are not directly connected to mains

stand: 09.07.2018
