WLX-2005
Introduction Thank you for purchasing the Sitecom WLX-2005 Wi-Fi Access Point N300. It complies with wireless 802.11b/g/n standards and can create a Wi-Fi network with data transmission rates of up to 300Mbps. With the WLX-2005, you can enjoy high-speed wireless networking throughout your home without additional cabling. The WLX-2000 features a WPS button which allows you to connect to the access point with a simple click of a button.
Table of Contents 1 KEY FEATURES ........................................................................................ 6 2 PACKAGE CONTENTS ............................................................................... 7 3 CAUTIONS .............................................................................................. 8 4 PRODUCT LAYOUT ................................................................................... 9 5 NETWORK + SYSTEM REQUIREMENTS ...........................................
1 KEY FEATURES Features Advantages Incredible Data Rate up to 300Mbps* Heavy data payloads such as MPEG video streaming IEEE 802.11n Compliant and backwards compatible with 802.11b/g Fully Interoperable with IEEE 802.11b / IEEE802.11g compliant devices with legacy protection Support 802.1x authenticator, 802.
2 PACKAGE CONTENTS Open the package carefully, and make sure that none of the items listed below are missing. Do not discard the packing materials, in case of return; the unit must be shipped back in its original package. 1. The WLX-2005 Wall Mount Access Point N300 2. A Quick Install Guide 3.
3 CAUTIONS This device’s design and manufacturer has your safety in mind. In order to safely and effectively use this device, please read the following before usage. 3.1 Usage Cautions The user should not modify this device. The environmental temperature should be within +5 ~ +35 degrees Celsius. 3.2 Power The device’s power voltage is AC 230v. When plugging in the device, make sure it cannot get damaged or be subject to pressure.
4 PRODUCT LAYOUT Description Network Port You can use this port to connect to a wired modem or router to add wireless functionality. OPS Button You can use this button to connect using OPS. OPS Button functions: Press 0-5 seconds: WPS registrar Press 15+ seconds: reset to factory defaults.
LED Description From left to right: LED Color Description Power Green Lights up when powered ON. Blinks on TEST/RESET. OPS Green Blinks when OPS mode is on. LAN Green Lights up when a LAN cable is connected. WLAN Green Lights up in Blue when WLAN is enabled. Blinks on traffic.
5 NETWORK + SYSTEM REQUIREMENTS To begin using the WLX-2005, make sure you meet the following as minimum requirements: PC/Notebook. 1 Free Ethernet port. WiFi card/USB dongle (802.11 b/g/n) – optional. PC with a Web-Browser (Internet Explorer, Safari, Firefox, Opera) Ethernet compatible CAT5 cables. Router or Access Point 6 WLX-2005 PLACEMENT You can place the WLX-2005 directly in a wall socket.
8 BRINGING UP THE WLX-2005 You can plug the WLX-2005 directly into a wall outlet. The WLX-2005 automatically enters the self-test phase. During self-test phase, the Power LED will be lit continuously to indicate that this product is in normal operation.
9 INITIAL SETUP WLX-2005 To configure the WLX-2005 connect to the device wirelessly as described in the Quick installation guide. Once the connection has been established follow the next steps to manually configure your access point. LOGIN procedure 1. OPEN your browser (e.g. Internet Explorer). 2. Type ‘http://sitecom.ap in the address bar and press [Enter] 3.
4. Click OK. 5. You will see the home page of the WLX-2005. The System status section allows you to monitor the current status of your device, the UP time, hardware information, serial number as well as firmware version information is displayed here.
11 BASIC SETTINGS Band Please select the wireless band you wish to use. By selecting a different band setting, you’ll be able to allow or deny the wireless clients on a certain band. MAIN ESSID Please input the ESSID (the name used to identify this wireless access point) here. You can input up to 32 alphanumerical characters. PLEASE NOTE THAT THE ESSID IS CASE SENSITIVE. Channel Number Please select a channel number you wish to use.
12 ADVANCED SETTINGS Security This device provides many types of wireless security (wireless data encryption). When you use data encryption, data transferred by radio signals in the air will become unreadable for those people who don’t know the correct encryption key (encryption password). There are four types of security level you can select: Disable (no security - data encryption disabled), WEP, WPA Pre-shared Key, and WPA Radius. Please refer to the following sections for detailed instructions.
WEP Key Length You can select the WEP key length for encryption, 64-bit or 128-bit. The larger the key will be the higher level of security is used, but the throughput will be lower. Key Format You may select ASCII Characters (alphanumeric format) or Hexadecimal Digits (in the "A-F", "a-f" and "0-9" range) to be the WEP Key. Key1-Key4 The WEP keys are used to encrypt data transmitted in the wireless network. Use the following rules to setup a WEP key on the device.
WPA WPA Unicast Cipher Suite Available options are: WPA (TKIP), WPA2 (AES), and WPA2 Mixed. You can select one of them, but you have to make sure your wireless client supports the cipher you selected. Pre-shared Key Format Please select the format of pre-shared key here, available options are ‘Passphrase’ (8 to 63 alphanumerical characters) and ‘Hex (64 hexadecimal characters – 0 to 9 and a to f). Pre-shared Key Please input pre-shared key according to the key format you selected here.
Advanced This tab allows you to set the advanced wireless options. The options included are Channel Bandwidth, Fragment Threshold, RTS Threshold, Beacon Interval, and Preamble Type. You should not change these parameters unless you know what effect the changes will have on the router. Fragment Threshold Set the Fragment threshold of wireless radio. The default value is 2346. RTS Threshold Set the RTS threshold of wireless radio. The default value is 2347.
different kinds of data, to give higher priority to applications which require instant response. Therefore you can improve the performance of such network applications. CTS Protect Enabling this setting will reduce the chance of radio signal collisions between 802.11b and 802.11g wireless access points. It’s recommended to set this option to ‘Auto’. TX Power You can set the output power of wireless radio.
WPS Wi-Fi Protected Setup (WPS) is the simplest way to establish a connection between the wireless clients and the wireless router. You don’t have to select the encryption mode and fill in a long encryption passphrase every time when you try to setup a wireless connection. You only need to press a button on both wireless client and wireless router, and WPS will do the rest for you. Check the box to enable the WPS function and uncheck it to disable the WPS function.
13 TOOLBOX SETTINGS System This device provides some control functions including password, IP address management, and DHCP server function. Please go to Toolbox, and open the ‘System’ tab, to access these functions. Below are detailed descriptions of every control function. Password Settings You can change the password used to enter the web configuration menu of this device.
DHCP Client End Address Please input the end IP address of the IP range. Domain Name If you wish, you can also optionally input the domain name for your network. This is optional. Lease Time Please choose a lease time (the duration that every computer can keep a specific IP address) of every IP address assigned by this access point from dropdown menu. After you finish, please click ‘Apply’.
Backup You can back up all configurations of this device to a file, so you can make several copies of access point configuration for security reasons. Backup Settings Press ‘Save...’ button, and you’ll be prompted to download the configuration as a file. The default filename is ‘config.bin’. You can save it as another filename for different versions, and keep it in a safe place.
Upgrade If there is a new firmware available, you can upload the firmware to the device to get extra functions or problem fixes. Click the ‘Browse’ button. You’ll be prompted to provide the filename of the firmware upgrade file. Please download the latest firmware file from our website, and use it to upgrade your device. After a firmware file is selected, click the ‘Apply’ button, and the device will start the firmware upgrade procedure automatically.
Reset When you think the device is not working properly, you can use this function to restart the device; this may help and solve the problem. This function is useful when the device is far from you or unreachable. However, if the device is not responding, you may have to switch it off by unplugging the power plug and plugging it back again after 10 seconds.
Parts of the firmware of the WLX-2005 Access Point are subject to the GNU general public license. Appendix A: Licensing Information This product includes third-party software licensed under the terms of the GNU General Public License.. You can modify or redistribute this free software under the terms of the GNU General Public License. Please see Appendix B for the exact terms and conditions of this license.
with two steps: (1) copyright the software, and (2) offer you this license which gives you legal permission to copy, distribute and/or modify the software. Also, for each author's protection and ours, we want to make certain that everyone understands that there is no warranty for this free software.
party, for a charge no more than your cost of physically performing source distribution, a complete machine-readable copy of the corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or, c) Accompany it with the information you received as to the offer to distribute corresponding source code.
the Free Software Foundation. If the Program does not specify a version number of this License, you may choose any version ever published by the Free Software Foundation. 10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are different, write to the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this.
