1011.0000.05
“Take the fourth turn on the right.”
This arrow shows you which exit you should take from a traffic circle.
1011.0000.06
“Follow the road in 400 ft.”
This arrow indicates you should drive strai ght ahead.
1011.0000.07
“Follow the arrows on the display.”
This display t ells you that you ar e curren tly in an area, such a s a parkin g lot, garage, etc. , that is not cont ained
on the digital street map. The arrow indicates the actual geographic direction to the destination.
1011.0000.08
“Keep right in half a mile.”
“Keep right” means that the street will fork and you should follow the indicated direction.
1011.0000.10
