Operationalprocedures
7ObservethattheTargettrackparameterdialogopensbelow
themenu.
8Choosethelengthofthetrackingline,andclickClosetoexit.
Usersettingprocedures
Thissectionexplainshowtohandleuseranddefaultsettings
ontheSH90sonar.
Howtosavethecurrentusersetting
1ClicktheSetuptabtoopenthemenu.
2ClicktheUsersettingbuttontoopentheparameterdialog.
3ClicktheSavecurrentsettingbutton.
Thecurrentsettingissavedwiththedefaultidentication
name.
Howtoloadausersetting
1ClicktheSetuptabtoopenthemenu.
2ClicktheUsersettingbuttontoopentheparameterdialog.
3Clickthedesiredusersettingtoselectit.
4ClicktheLoadbutton.
5ClickOKinthenextparameterdialogtoconrmthe
selection.
Theselectedsettingisloaded.
Howtorenameausersetting
Note
Inprinciplesyoucanuseanyname,buttheModebuttonsonthe
OperatorPanelwillonlychoosefromUser1,User2,User3
andUser4.Thesenamesmustalsobeonthetopofthelist.If
youwishtoaddusers,applynameslikeforexample“User5
Charlie”.
1ClicktheSetuptabtoopenthemenu.
2ClicktheUsersettingbuttontoopentheparameterdialog.
3Clicktheoneoftheusersettingsonthelisttoselectit.
4ClicktheRenamebutton.
•Observethataparameterdialogopenstopresentthe
currentname.
