SimradSH90
Automaticsearchandtrackingprocedures
TheSH90sonarprovidesyouwithtwoautomaticsearch
programs,horizontalandvertical.Bothareinitiatedfromthe
OperatingUnit
Howtostartthehorizontalsearchprogram
Observethefollowingproceduretoruntheautomaticsearch
program.
(CD015022-008)
TRAIN
Target
Track
Position
Track
Manual
Auto
Search
Procedure
1PresstheAutosearchbuttonintheTraineldonthe
OperatingPaneltostartthehorizontalsearchprogram.
2HoldtheAutosearchbuttondepressedwhileyoualsopress
oneofthetwo“arrow”buttonsintheTraineld.
3Observethattheopeningangleofthesearchsectoris
adjustedaccordingly.
4ReleasetheAutosearchbutton,pressandholdoneofthe
two“arrow”buttons.
5Observethatthecentreofthesearchsectoristrained
accordingly.
Toexitthesearchprogram,presstheManualbutton.
Howtostarttheverticalsearchprogram
Observethefollowingproceduretoruntheautomaticsearch
program.
Procedure
1PresstheAutobuttonintheTilteldontheOperatingPanel
tostarttheverticalsearchprogram.
Auto
2HoldtheAutobuttondepressedwhileyoualsopressoneof
thetwo“arrow”buttonsintheTilteld.
