Operationalprocedures
2Observethattheoperatingsystem’sauto-startfunction
opensadialoguerequestingguidance.
3SelectOpenwritableCDfolderusingWindowsExplorer,and
clickOK.
4ObservethataWindowsExplorerwindowopens.
5BymeansofnormalWindowsfunctions,navigatetothe
folderd:/winson/screendumps.
6Double-clicktoopensub-folderPermanentorTemporary.
7ClicktoselecttheimagesyouwishtoburnontheCD,and
copythemtotheCD’sWindowsExplorerwindow.
8ClickWritetheselestoCDintheWindowsExplorer
window,andwaituntiltheprocesshasnished.
9RemovetheCD,andclosetheWindowsExplorerwindow.
HowtocopysonarimagestoaUSB
memorystick
TheSH90ProcessorUnitisprovidedwithseveralUSBinterface
ports.Thesearelocatedontherearsideofthecabinet,andon
somemodelsbelowtheCDplayerunderthefrontcover.Observe
thefollowingproceduretocopyselectedsonarimagesoverto
aUSBmemorystick.Donotattemptthiswhilethesonarisin
usesearchingforsh!
Note
Thisprocedureassumesthatyouhavebasicknowledgeofle
managementinWindows.
1InsertaUSBmemorystickintotheProcessorUnit.
2Observethattheoperatingsystem’sauto-startfunction
opensadialoguerequestingguidance.
3SelectOpenWindowsExplorer,andclickOK.
4ObservethataWindowsExplorerwindowopens.
5BymeansofnormalWindowsfunctions,navigatetothe
folderd:/winson/screendumps.
6Double-clicktoopensub-folderPermanentorTemporary.
7ClicktoselecttheimagesyouwishtocopytotheUSB
memorystick,andcopythemtotheUSB’sWindows
Explorerwindow.
8RemovetheUSBmemorystick,andclosetheWindows
Explorerwindow.
Toaccesstheoperatingsystemfunctions,youcanclickanyHelp
button.Whenthehelpwindowopens,youcanalsoaccessthe
TaskbarwiththeStartbutton.
323775/B
53
