Operationalprocedures
Preparetherecordingparameters
1ClicktheSetuptabtoopenthemenu.
2ClicktheStore/RecallbuttontoopentheStore/Recallmenu.
3ClicktheStoremodebuttontochooserecordingmode.
ClicktheleftsideoftheStoremodebuttontoscrolldown
thelistofoptions.Clickthemiddleofthebuttontoopen
theparameterdialoguefordirectaccesstotherequested
setting,orclicktherightsideofthebuttontoscrollupthe
listofoptions.
4Recordtheimages.
5ClicktheClosebuttontoclosetheStore/Recallmenu.
Oncetherecordinghasbeenactivated,thesonarwillsave
sonarimagesasdenedbytheStoremodesetting.Each
imageisaddedtothelistoftemporaryleslocatedbelow
thebuttons.Eachlenamereectsthedateandtime.
Recordasingleimage
1Torecordasingleimage:
AClicktheStorebutton.
or
BPresstheRecordbuttonontheOperatingPanel.
2Observethatthemessageeldbelowthemenudisplaysthe
imagelenameonagreenbackground.
Recordmultipleimages
1Tostartrecording:
AClicktheStorebutton.
or
BPresstheRecordbuttonontheOperatingPanel.
2Observethatthemessageeldbelowthemenudisplaysthe
imagelenamesonagreenbackground.
3Tostoprecording:
AClicktheStorebutton.
or
