SimradSH90
•Theidentication(ID)abbreviationsforthedifferent
objectsare:
–AT:Automatictargettrackmarker
–Ci:Circlemarker
–M:Targetmarker
–OS:OwnShipmarker
–PT:Positiontrackmarker
–F:Radiobuoymarker
•ThenumberbehindtheIDabbreviationreferstothe
samenumberontheobjectinthesonarpresentation.The
“P”aftertheAutomatictargettrackmarkerindicatesthe
prioritylevelwheretheaudiochannelislockedtothe
target.
•WhenyouselectaTargetmarker,Automatictargettrack
markeroraRadiobuoymarkerinthelist,adottedbearing
linefromthevesseltothemarkerwillbeshown.
3Toretrievetheinformationaboutanobject,clicktheobject
abbreviationinthelist.
4Observethatadedicatedparameterdialogwithallknown
objectinformationappearsatthebottomofthemenu.
Howtodeleteamarkerorsymbol
1ClicktheObjectstabtoopenthemenu.
2Clickontheobjectthatyouwishtodelete.
3ClicktheDeletebuttonatthebottomofthelist.
Alternativemethod
1Placethecursorontheobject.
2PresstheObjectbuttonontheOperatingPanel(orther
i g h t
mousebutton)
3ClickDeleteonthemenu.
Storageprocedures
Thissectionexplainshowtostoreandrecallsonarimageson
theSH90.
Howtostoresonarimages
NotethattheRecordbuttonontheOperatingPanelcanbe
pressedatanytimetostartrecording.Itisnotnecessaryto
opentheStore/Recallmenurst.Whenthisbuttonisused,the
currentlyselectedrecordingmodewillbeused.
