SimradSH90
HowtoadjusttheAGC
TheAGC(AutomaticGainControl)adjuststhegaininthe
sonar’spreampliercircuitry.Thisgaindependsonthestrength
oftheincomingechosignal.Theresultisaltereffect,reducing
noiseandreverberation.TheAGChasfourdifferentsettings.
1ClicktheHorizontalorVerticaltabtoopentherespective
menu.
2ClicktheAGCbuttontoadjusttheparameter.
ClicktheleftorrightsideoftheAGCbuttontodecrease
orincreasethesetting,orthemiddleofthebuttontoopen
theparameterdialog.
Formoreinformationaboutthisparameter,seeWhatisAGC?
onpage179.
HowtoadjusttheRCG
TheRCG(ReverberationControlledGain)regulatesthereceiver
gainindividuallyforeachofthereceivingbeams.Ifyouselect
asmallormediumvalue,echoesfrompropellers,surfaceand
bottomreverberationswillbesuppressed,whiletargetechoes
willremaininview.Ifyouselectastrongltersetting,itwill
removethebottom,whileechoesonthebottomwillbepresented.
Note
Scatteredshcanbeperceivedasreverberation.TheRCG
functionmustthereforebeusedwithcareifyouwishtond
scatteredschools.
1ClicktheHorizontalorVerticaltabtoopentherespective
menu.
2ClicktheRCGbuttontoadjusttheparameter.
ClicktheleftorrightsideoftheRCGbuttontodecrease
orincreasethesetting,orthemiddleofthebuttontoopen
theparameterdialog.
Formoreinformationaboutthisparameter,seeWhatisRCG?
onpage181.
