SimradSH90
OPERATIONALPROCEDURES
Thischapterpresentshowtoperformthemostcommon
proceduresontheSH90sonar.Notethatthepoweron/off
procedureshavebeenpreviouslyexplained.
Topics
•Poweron/offproceduresonpage38
•Menuproceduresonpage40
•Gainadjustmentproceduresonpage41
•Modeproceduresonpage43
•Markersandsymbolsproceduresonpage45
•Storageproceduresonpage48
•Automaticsearchandtrackingproceduresonpage54
•Usersettingproceduresonpage57
•Installationofoptionsonpage58
•Softwareproceduresonpage60
Poweron/offprocedures
Theseproceduresexplainhowtoswitchthesonarsystemonand
off.Theoperationismadeusingthebuttonsontheoperating
panel.
Figure17OperatingPanel
Howtoswitchonthesonar
ThisprocedureexplainshowtopoweruptheSimradSH90.
1PressthePowerbuttononthecolourdisplaymonitor.
2PressthePowerbuttonontheOperatingPanel,andkeepit
depressedforapproximatelytwoseconds.
POWER
•Thegreenlampontherightsideofthebuttonwillash
toindicatedthatthepowerhasbeenswitchedon,andthat
thecomputerisstartingup.
