SimradSH90
Note
Inthismanual,thephrase“Clickthebutton”meansthatyou
shallpositionthecursoroverthemenubutton,andthenpress
theSelectbuttonontheOperatingPanel.
Certainparametersettingsareidentiedwithanasterisk(*).This
symbolindicatesthedefaultsettingknowntoperformwellunder
normalconditions.Ifyouget“lost“intheparametersettings,the
Defaultsettingsfunctionwillbringupthesenormalparameters.
TheDefaultsettingfunctionisavailableontheSetupmenu,anda
dedicatedparameterdialogisused.
IntheSimradSH90sonar,allparametersarestored.This
functionwillcausethesonartorememberalltheselected
parametersettings,evenwhenthesonarisswitchedoff.
Visualaids
Thesonardisplaycontainsnotonlythesonarpictureandthe
menusystem,butalsootherinformationthatisusefulfor
efcientoperation.
Commoninformationonthedisplay
Innearlyalldisplaymodes,thefollowinginformationis
provided.
Figure13Visualaids
(CD015013A)
AB
C
D
E
F
ACurrenthorizontalgain.
BCurrenthorizontalrange.
CThecursor’ scurrentgeographicalposition(providedthat
thenecessarysensorisconnectedtothesonar).
DThecursor’scurrentbearingrelativetothevesselortrue
north.
ECurrenttilt.
FCurrentrangeanddepthofthecursorposition.
32
323775/B
