Gettingstarted
4Pleasenote:
•Ifthesonarisswitchedoffuncontrolledwiththe
transducerinitsloweredposition,thetransducerwill
normallybehoistedautomaticallyafterapproximately
oneminute.Youmusthoweververifythatthistakes
place.Ifthetransducerisn
o t hoistedautomatically,itcan
beraisedmanuallybymeansofthehoist/lowerswitchin
theMotorControlUnit.Ifmainspowerislost,youcan
alsousethehandcrankprovided.
Howtoperformbasicoperations
Observethisbriefproceduretofamiliarizeyourselfwiththe
basicoperationswithechopresentationsandmenuoperations.
Echopresentationandmenu
1Oncethesonarsystemisupandrunning,observethelayout
ofthedisplaypresentation:
•Onther
i g h t side,observethemenusystem(A).
•Onthel
e f t side,observethesonarechopresentation(B).
Figure10Basicmenu(A)andechopresentation(B)
2OntheOperatingPanel,presstheMenubutton(located
abovethelargetrackball).
Menu
