SimradSH90
4PresstheDownbuttononthecontrolpaneltolowerthe
transducer.
Down
•Thegreenlampnexttothebuttonwillash,andan
audiblesignalindicatesthatthetransducerislowered.
•Whenthelowerpositionhasbeenreached,thelamp
willbelitcontinuously,theaudiblesignalstops,and
thetopbuttonintheStatusparameterdialogshows
Transducer:Down.
•Bydefaultthetransmitpowerisdisabledwhenthe
sonarispoweredup.Thisisforsafetyreasons.Onthe
Horizontalmenu,youwillseethattheTXpowerbutton
ashestoremindyouofthis.
5ClicktheTXpowertoselectFull.
Howtoswitchoffthesonar
ThisprocedureexplainshowtopowerofftheSimradSH90.
1PresstheUpbuttonontheOperatingPanel.
Up
•Thegreenlampnexttothebuttonwillash,andan
audiblesignalindicatesthatthetransducerishoisted.
•Whentheupperpositionhasbeenreached,thelampwill
illuminatecontinuously,theaudiblesignalstops,andthe
upperbuttonintheStatusmenushowsTransducer:UP.
2PressthePowerbuttonontheOperatingPanel,andkeepit
depressedforapproximatelytwoseconds.
POWER
3Switchoffthedisplaymonitor.
26
323775/B
