Figure6Omni/verticalcombination
InadditiontotheOmnipicture,theverticalsliceisespecially
usefulforvisualizingtheverticaldistributionofaschoolof
sh.Inthatway,itisnotnecessarytogooverthetargettosee
thedistributionontheechosounder,whichoftenresultsina
spreadingoftheschool.
Stabilisationsystem
TheSimradSH90isprovidedwithastabilisationsystem.
Whenthebeamstabilizerisactivated,bothhorizontaland
verticalbeamswillbestabilizedelectronicallyforrollandpitch
movementsupto±20degrees.Thebeamdirectionwillthen
changecontinuouslyaccordingtothevessel’smovements,and
secureanoptimalcontactwiththetargetseveninroughseas.
Figure7Stabilisationsystem
