SimradSH90
TransceiverUnitHeatExchanger
Asanoption,theTransceiverUnitmaybeprovidedwithaHeat
Exchanger.TheltersandfansinthisHeatExchangermustbe
cleaned.Thisprocedureexplainshowtodothat.
Note
TheHeatExchangerisanoptionalitem.Ifitisnotmountedon
yourTransceiverUnit,disregardthisprocedure.
1OpenthefrontpanelontheHeatExchangerbyremoving
thefourboltsindicatedontheillustrations.
Figure48HeatExchangerfrontpanelmountingbolts
(A)removal
2Useavacuumcleanerwithaplasticorrubbernozzle,aswell
assoftclothmoistenedinfreshwater,tocleantheinterior.
3Remountthefrontpanel.
TransceiverUnitserviceableparts
TherearenouserserviceablepartsinsidetheTransceiverUnit.
192
323775/B
