SimradSH90
WindDirectiondialogoptions
•+(plus):Clicktoincreasethewinddirection.
•–(minus):Clicktodecreasewinddirection.
•Manual:Clicktoenablemanualsettingofthewinddirection.
•Auto:Clicktoenableautomaticsettingofthewinddirection.
Theinformationmustthenbeprovidedfromanexternal
sensorconnectedtothesonar.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Setupmenuonpage99
Zoom
Dialogdescription
TheZoomparameterdialogopenswhenyouclicktheZoom
buttonintheVerticalViewmenu.
Thezoomfunctionisusedtozoominontheverticalviewaround
thetrawlsymbolorthebottom.Tozoominonthebottom,an
externalechosoundermustbeconnectedtothesonar.
Zoomdialogoptions
•FullRange:Clicktousethefullrangeinthevertical
presentation.
•Trawl:Clicktozoominonthetrawl.
•Bottom:Clicktozoominonthebottom.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•VerticalViewmenuonpage112
