Parameters
•SaveCurrentSettings:Usethisoptiontosaveallthecurrently
usedparametersettings.Youwillalwayssaveyourcurrent
settingasa“newuser”.Bydefaultthesettingwillbenamed
UserN,and“N”issimplythenextavailablenumber.
Note
Inprinciplesyoucanuseanyname,buttheModebuttonson
theOperatingPanelwillonlychoosefromUser1,User2,
User3andUser4.Thesenamesmustalsobeonthetopof
thelist.Ifyouwishtoaddusers,applynameslikeforexample
“User5Charlie”.
•Delete:Clicktoselectoneofthesettingsinthelist,thenclick
thisbuttontodeleteit.
•Rename:Thisoptionprovidesanon-screenkeyboardto
renamethestoredusersetting.Clickonasettingtoselectit,
thenclickthisbutton.Enterthenewnameusingtheon-screen
keyboard.
•Selectusers:BymeansofthefourModebuttonsonthe
OperatingPanelyoucanselectthefourtopusersonthelist.
Thelistofusersissortedalphabetically,andyoucanrename
theusersandthuscontrolwhichModebuttontorecallwhich
user.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Usersettingproceduresonpage57
•Setupmenuonpage99
WindDirection
Dialogdescription
TheWindDirectionparameterdialogopenswhenyouclickthe
WindDirectionbuttonintheSetupmenu.
Thewindmarkerisshownasawhitearrowintheouterareaof
theechopresentation.Thisarrowcanbemanuallyadjustedfor
indicationofthewindorcurrentdirection,orautomaticallyshow
thewinddirectionifawindsensorisconnected.
323775/B
175
