SimradSH90
EngineeringUnitsdialogoptions
•Range:Clicktochangeunitforrange.SelectMeters,
Nauticalmile,FeetorYards.
•Equipment:Clicktochangeunitforequipment.SelectMeter,
FathomsorFeet.
•Depth:Clicktochangeunitfordepth.SelectMeters,Fathoms
orFeet.
•Speed:Clicktochangeunitforspeed.SelectMeters/Second
(m/s),KnotsorKilometres/Hour(km/h).
•Position:Clicktoviewunitforgeographicalposition.
•Temperature:Clicktochangeunitfortemperature.Select
CelsiusorFahrenheit.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Displaymenuonpage98
UserSetting
Dialogdescription
TheUserSettingparameterdialogopenswhenyouclicktheUser
SettingbuttonintheSetupmenu.
Thisparameterdialogisusedtostoretheparametersettingsfor
differenttypeofsheries,orindividualuserrelatedsettings.The
storedsettingscaneasilybeloadedbackintotheoperativemenus
usingtheModebuttonsontheOperatingPanel.
FormoreinformationabouttheModebuttonsontheOperating
Panel,see’Mode’eldonpage85.
UserSettingdialogoptions
•LoadSelectedSetting:Usethisoptiontoretrievethe
previouslystoredsetting.Clickonthechosensettinginthe
dialogtohighlightit,andthenclickthisbuttontoretrieveit.
174
323775/B
