SimradSH90
•TransducerPos(ition):Thisisaread-out(incentimetres)of
thetransducer’scurrentposition.
•MiddlePos(ition):Thisisthedenedmiddleposition(in
centimetres)ofthetransducer.Tochangetheposition,click
thebutton.
•Down:Clicktolowerthetransducertoitsbottomposition.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Statusonpage162
•MiddlePos(ition)onpage143
TRUOn/Off
TheTRUOn/Offdialogopensautomaticallywhenyouswitch
thesonaronoroff.ItwillalsoappearwhenyouclicktheTRU
On/OffbuttonontheSystemTestmenu.
Figure38Systemstart-upinprogress
Thisdialogisusedtomonitortheprogresswhenthesonar
systemisswitchedonoroff.Thevariousstagesintheprogress
isindicatedwiththerectangulargreen“lamps”,whiletheblue
progressbarshowstheoverallprogress.Thecircularlampinthe
toprightcornerisanindicatorthatshowsiftheTransceiverUnit
ispresentlystarting(green)orstopping(red).
170
323775/B
