Parameters
•Each5ths:Clicktorecordthesonarechoesonceeveryfth
secondinaseriesofseparateimages.
•Each10ths:Clicktorecordthesonarechoesonceeverytenth
secondinaseriesofseparateimages.
•Each30ths:Clicktorecordthesonarechoesonceeveryhalf
minuteinaseriesofseparateimages.
•Each60ths:Clicktorecordthesonarechoesonceevery
minuteinaseriesofseparateimages.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Setupmenuonpage99
•Store/Recallmenuonpage104
•Storeonpage163
•Recallonpage154
•RecallModeonpage154
TargetTrack
Dialogdescription
TheTargetTrackparameterdialogopenswhenyouclickthe
TargetTrackbuttonintheGeoViewmenu.
TheGeoViewmenuisinturnactivatedbypressingtheView
buttonontheOperatingPanel(orthem
i d d l e mousebutton)in
anyhorizontalview,andthenselectingViewmenuintheView
pop-upmenu.
Targettracklinesshowthemovementhistoryoftargetsasaline
aftertherespectivesymbols.Theyareshownasstraightline
segmentsdrawnbetweeneachpositionx,withoptionalminute
markerstobeaddedforeachminutealongtheline.Y oucan
switchthetrackline(s)off,orenablethemfortheprioritytarget
only(P),orforalltargets.
