SimradSH90
Figure35Truerange(A),slantrange(B)andtiltangle(C)
(CD15023A)
C
A
B
Relatedtopics
•Cosmeticsmenuonpage103
•TrueRangeonpage172
Speed
Dialogdescription
TheSpeedparameterdialogopenswhenyouclicktheSpd
(Speed)buttonintheStatusparameterdialogatthebottomof
themenus.
Thespeedread-outisarepetitionoftheconnectedspeedinput
source,whichcanbeaseparatespeedloginputordatafromthe
connected(D)GPS.Incaseofafaultinthespeeddata,thespeed
canbesetmanuallybyclickingManualandusingthe+and-
buttonstoalterthespeedvalue.
160
323775/B
