Parameters
SearchStep
Dialogdescription
TheSearchStepparameterdialogopenswhenyouclickthe
SearchStepbuttonintheBearingparameterdialog.TheBearing
parameterdialogopenswhenyouclicktheBearingbuttoninthe
Horizontalmenu.
Thisparameterdialogisusedtodenethesizeofeachstep(in
degrees)theaudiobeamwilltravelbetweeneachtransmission.
ThisfunctionisusedwhentheAutoSearchmodeisenabled.
SearchStepdialogoptions
•+(plus):Clicktoincreasethestepsize.
•–(minus):Clicktodecreasethestepsize.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Bearing(Horizontal)onpage125
•SearchSectoronpage158
SlantRange
Dialogdescription
TheSlantRangebuttonislocatedintheCosmeticsmenu,which
inturnisopenedfromtheDisplaymenu.
ThisisatoggleswitchwhichallowsyoutochoosebetweenSlant
RangeandTrueRange.
•TrueRange:Thisisthedistancewhichthevesselmustsailin
ordertocomeontopofthetarget.
•SlantRange:Thisisthedistancetothetargetmeasuredalong
thetiltangle.
323775/B
159
