Parameters
SchoolData
Dialogdescription
TheSchoolDataparameterdialogopenswhenyouclickthe
SchoolbuttonintheSetupmenu.
Thisparameterdialogisusedtoobtaininformationofthe
volumeestimationofaschoolintheautomatictargettracking
program.Fivetypesofknownshspeciesplus“ownschool”
canbeselected.Assumeddensitycanbeadjustedaccordingto
experiencebyuseoftheEditSchoolbutton.
SchoolDatadialogoptions
1[Species]:Clicktochoosethepreferredspecies.
2Edit:ClicktoopentheEditSchoolparameterdialog,which
allowsyoutochangethedensityofthechosenspecies.
3Close:Clicktoclosetheparameterdialog.
4Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Setupmenuonpage99
•EditSchoolonpage135
ScienticOutput
Dialogdescription
TheScienticOutputparameterdialogopenswhenyouclickthe
ScienticOutputbuttonintheSetupmenu.
Note
TheScienticOutputfunctionisoptional.
TheScienticOutputfunctionisdesignedtobeusedwhenthe
sonarisusedforscienticpurposes.Whenenabled,thesonar
willexportspecialinformationonadedicatedEthernetport.This
parameterdialogallowsyoutospecifythedataformats.
323775/B
157
