Parameters
RCG
Dialogdescription
TheRCG(ReverberationControlledGain)parameterdialog
openswhenyouclicktheRCGbuttonintheHorizontal,Vertical
andVertical180menus.
ReverberationControlledGain(RCG)regulatesthereceivergain
individuallyforeachofthe64receivingbeams.Ifyouselect
weakormediumlterstrength,signalswithsmallvariations,
likepropellernoise,surfaceandbottomreverberationswillbe
removed,whilesignalswithfastvariations,liketargetechoes
orbottomechoes,willnotberemoved.Ifyouselectastrong
lter,aspecialfunctionremovesthebottom,whileechoeson
thebottomwillbepresented.
Note
Scatteredshcanbeperceivedasreverberation.TheRCG
functionmustthereforebeusedwithcareifscatteredschools
aretobedetected.
RCGdialogoptions
•Off:Clicktoswitchthelteroff.
•Weak:Clicktoswitchonaweaklter.
•Medium:Clicktoswitchonamediumlter.
•Strong:Clicktoswitchonthespecialltertoremovethe
bottomechoes.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•WhatisRCG?onpage181
•Horizontalmenuonpage93
•Verticalmenuonpage95
•Vertical180menuonpage96
323775/B
153
