Parameters
ModeButtons
Dialogdescription
TheModeButtonsbuttonislocatedontheDisplaymenu.
Thisissimplyaselectorswitch.Clickonthebuttontoselect
ModeorUser,andbythisdeningtheoperationalfunctionof
thefourModebuttonsontheOperatingPanel.
FormoreinformationabouttheModebuttonsontheOperating
Panel,see’Mode’eldonpage85.
ModeButtonsoptions
•Mode:ThefourModebuttonsontheOperatingPanelcanbe
usedtoselectfromyourfavouritedisplaymodes.
WhentheModebuttonsontheOperatingPanelareusedto
selectdisplaymodes,thefourbuttonswillselectthefourtop
displaymodesinthesameorderastheyappearintheSort
Modesmenu.
•User:ThefourModebuttonsontheOperatingPanelcanbe
usedtoselectbetweenfourfavouriteusersettings.
Relatedtopics
•Displaymenuonpage98
•SortModesmenuonpage107
•Modeonpage144
Movements
Dialogdescription
TheMovementsparameterdialogopenswhenyouclickthe
MovementsbuttonontheSetupmenu.
Thisfunctionmakesitpossibletoestimatethepositionof
atrackedschoolatagiventime(fromonetotenminutes).
Estimatedschoolpositionispresentedbyavioletdot.Ifyou
select0,themovementestimationisswitchedoff.
