Parameters
TheMessageBarislocatedatthebottomofthedisplay.It
containsfourbuttons,oneforeachcategoryofmessages.These
buttonsgiveanoverviewofthenumberofunreadmessages
currentlyinthesystem,andeachofthefourbuttonsgivesaccess
toamenuwhereeachmessagecanberead,acknowledgedand
deleted.Whennomessagesarepresent,thefourbuttonsaregrey.
Whenoneormoreunreadmessagesexists,theWarningand
OperationalAlarmbuttonsareyellow,whiletheSystemAlarm
andErrorbuttonsarered.
MessageBardialogoptions
•Off:ClicktoswitchofftheMessageBar.Itwillnotbeshown,
evenifmessagesareissued.
•OnError:ClicktoallowtheMessageBartoappearonly
whenerrormessagesareissuedbythesonar.
•OnSys.Alarms:ClicktoallowtheMessageBartoappearonly
whensystemalarmsareissuedbythesonar.
•OnOp.Alarms:ClicktoallowtheMessageBartoappearonly
whenoperationalalarmsareissuedbythesonar.
•OnWarning:ClicktoallowtheMessageBartoappearonly
whenwarningsareissuedbythesonar.
•AlwaysOn:ClicktoswitchtheMessageBarpermanentlyon.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Setupmenuonpage99
•SystemTestmenuonpage105
MiddlePos(ition)
Dialogdescription
TheMiddlePos(ition)parameterdialogopenswhenyouclickthe
MiddlePosbuttonintheTransducerparameterdialog.
Thisparameterdialogallowsyoutodenea“middle”position
forthetransducer.Suchapositionmayforexamplebethe
positionwherethetransducerislocatedimmediatelybelowthe
trunk.
