SimradSH90
Headingdialogoptions
•+(plus):Clicktoincreasethemanualheadingwith1degree.
•–(minus):Clicktodecreasethemanualheadingwith1
degree.
•Manual:Clicktoallowmanualheading.Usethisoptiononly
iftheship’sheadingsensorisunavailable.
•Auto:Clicktouseautomaticheadinginformationfromthe
ship’sheadingsensor.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Setupmenuonpage99
InspectObject
Dialogdescription
TheInspectObjectparameterdialogiseitheropenedwhenyou
selectatargetmarkerintheObjectsmenu,orwhenyouplace
thecursoronthemarkerandpushestheSelectbuttononthe
OperatingPanel.Youcanalsoopenthisdialogdirectlyfrom
theObjectpop-upmenuwhenyouhaveplacedthecursorover
thetarget.
Thisparameterdialogdisplaysthecurrentparametersforthe
chosenobject.Notethateveryparametermaynotbeapplicable
forallmarkercategories.
FormoreinformationabouttheOperatingPanel,see’Cursor’
eldonpage86.
InspectObjectdialogoptions
•Depth:Thisread-outshowsthecurrentdepthofthechosen
object.
•Distance:Thisread-outshowsthecurrentdistancetothe
chosenobject.
•Bearing(B):Thisread-outshowsthecurrentbearingtothe
chosenobject.
•Speed(S):Thisread-outshowsthecurrentspeedofthechosen
object.
•Course(CO):Thisread-outshowsthecurrentcourseofthe
chosenobject.
•GeographicalPosition:Thisread-outshowsthecurrent
geographicalpositionofthechosenobject.
140
323775/B
