Geardialogoptions
•Purse:Clicktoselectsmall,mediumorlargepurse.
•BottomTrawl:Clicktoselectsmall,mediumorlargebottom
trawl.
•PelagicTrawl:Clicktoselectsmall,mediumorlargepelagic
trawl.
•Edit:Clicktoopenadedicatedparameterdialogtoeditthe
parametersofthechosengear.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Setupmenuonpage99
•EditGear(Purse)onpage133
•EditGear(Trawl)onpage134
Heading
Dialogdescription
TheHeadingparameterdialogopenswhenyouclicktheHdg
(Heading)buttonintheStatusparameterdialogatthebottom
ofthemenus.
Theread-outofthecurrentheadingisarepetitionofthe
connectedcoursegyroinput.Thisparameterdialogallowsyou
tosetamanualheadinginputifthesignalsfromtheexternal
headingsensorsaremissing.
Note
Thisheadingread-outmustn o t beusedfornavigation.
