SimradSH90
ExternalSynchronisationdialogoptions
•Syncmode:Clicktoselectoneofthethreesynchronization
modesbelow.
•ModeNone:ClicktodisconnecttheSH90fromthe
synchronisationsystem.Thesonarwillthenoperate
completelyonitsown.
•ModeSlave:ClicktoconnecttheSH90asaslavetoan
externalsystem.Theexternalsystemwilltheninstructthe
sonarwhentotransmit.
•ModeMaster:ClicktoallowtheSH90tobeincontrol.The
sonarwilltheninstructtheexternalsystemonwhenitcan
transmit.
•Delay:ClicktoselectthedelaybetweentheSH90
transmissionandthetransmissionoftheexternalsystem,
orviceversa.Adedicateddialogisprovidedtomakethe
selection.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Setupmenuonpage99
FishAlarm
Dialogdescription
TheFishAlarmparameterdialogopenswhenyouclicktheFish
AlarmbuttonontheSetupmenu.
Thisisanon/offswitchusedtoactivateordeactivatethesh
alarmfunction.Youcandeneanalarmareawithinnerandouter
rangeradiusandachosenwidth,andselectanalarmthreshold.
Whenshisdetectedwithinthearea,thealarmwillbeinitiated.
Tomutethealarm,presstheMutebuttonontheOperatingPanel.
