SimradSH90
EditGear(Trawl)
Dialogdescription
TheGearparameterdialogopenswhenyouclicktheGearbutton
ontheSetupmenu.EachoftheavailableoptionsintheGear
dialogcanbeeditedusingtheEditbutton.Whenatrawlhasbeen
selected,thisEditGearparameterdialogisprovided.
Theseparametersallowsyoutomonitorordenethedistance
anddepthofyourtrawl,aswellastheheightandwidthof
yourtrawlopening.IfyouusetheSimradITIsystem,these
parameterswillbeprovidedautomatically.
EditGear(Trawl)dialogoptions
•Distance:Clicktodenethedistancetothetrawl.Thesetting
isautomaticallyifyouclicktheAutobutton,providedthata
Simradtrawlsystemisconnectedtothesonar.Ifyouclick
Manual,youcandenethedistanceinstepsof10meters.
•Depth:Clicktodenethedepthofthetrawl.Thesettingis
madeautomaticallyifyouclicktheAutobutton,providedthat
aSimradtrawlsystemisconnectedtothesonar.Ifyouclick
Manual,youcandenethedepthinstepsof10meters.
•Height:Clicktodenetheheightofthetrawlopening.The
settingismadeautomaticallyifyouclicktheAutobutton,
providedthataSimradtrawlsystemisconnectedtothesonar.
IfyouclickManual,youcandenetheheightinstepsof1
meter.
•Width:Clicktodenethewidthofthetrawlopening.The
settingismadeautomaticallyifyouclicktheAutobutton,
providedthataSimradtrawlsystemisconnectedtothesonar.
IfyouclickManual,youcandenethewidthinstepsof10
meters.
•Length:Clicktodenethelengthofthetrawlsymbolon
thesonardisplay.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Setupmenuonpage99
•Gearonpage138
•EditGear(Purse)onpage133
