Parameters
Density
Dialogdescription
TheDensityparameterdialogopenswhenyouclicktheEdit
buttonintheEditSchoolparameterdialog.TheEditSchoolisin
turnopenedfromtheSchoolDatabuttonontheSetupmenu.
Thisparameterdialogisusedtodenethedensityofthecurrent
shspecies.
Thedefaultdensityvalueis25kg/m².Youmayadjustthisvalue
basedonyourownexperiencefromknowcatches.
Densitydialogoptions
•+(plus):Allowsyoutoincreasethedensity.
•–(minus):Allowsyoutodecreasethedensity.
•Close:Clicktoclosetheparameterdialog.
•Help:Clicktoaccesstheon-linehelp.
Relatedtopics
•Setupmenuonpage99
•EditSchoolonpage135
•SchoolDataonpage157
DirectionIndicator
Dialogdescription
TheDirectionIndicatorparameterdialogopenswhenyouclick
theDirectionIndicatorbuttonintheV erticalViewmenu.Note
thatDataSourcemustbesettoIndicatorinordertoaccessthis
parameter.
TheVerticalViewmenuisactivatedbypressingtheViewbutton
ontheOperatingPanel(orthem
i d d l e mousebutton)while
positioningthecursorinanyoftheverticalviews,andthen
selectingViewmenuontheViewpop-up.
Thisfeatureallowsyoutotraintheverticalslicesindependent
oftheaudiochannel.TheDirectionIndicatorisshowninthe
horizontalpresentationasayellowdottedline.
DirectionIndicatordialogoptions
•+(plus):Clicktoincreasethedirectionangle.
323775/B
131
