SimradSH90
Relatedtopics
•Horizontalmenuonpage93
Bearing(Display)
Dialogdescription
TheBearing(Display)parameterisactivatedwhenyouclickthe
BearingbuttonintheDisplaymenu.
Thisissimplyaselectorswitch.Clickonthebuttontoselect
TruenorthorRelativeShip.Certainbearingdatawillchange
theirvaluesaccordingly.Thefollowingbearingdatawillchange
whenyouswitchbetweenthetwosettings:
•Cursorbearing
•MarkersbearingintheObjectsmenu
•Targetpositionsinthecatchdataviews
Note
Therearenoindicationonanyoftheseread-outvaluestoidentify
themasrelativeortrue.
Allotherbearingdataremainpermanent,andwillnotchange
whenyouselectrelativeortruebearing.Thisincludes:
•Winddirectionisalwaysrelativetotruenorth
•Audiolineisalwaysrelativetotheship’sheading
•Ship’scurrentheadingisalwaysrelativetotruenorth
•Target’scurrentheadingisalwaysrelativetotruenorth
Relatedtopics
•Displaymenuonpage98
•Objectsmenuonpage101
