Menudescriptions
SystemAlarmsmenu
Menudescription
TheSystemAlarmsmenuisactivated
fromtheSysAlarmsbuttonintheMessage
Bar.(►MessageBaronpage142)
Themenudisplaysthesystemalarms
issuedbythesonar.
Eachmessageisidentiedwithtime
ofissueandaheading.Additional
informationisfoundinthesmalltext
eldbelowthemessagelist.Thetop
ofthemessagelistwiththemostrecent
messagesisalwaysdisplayedwhen
thedialogisopened.Acknowledged
messagesaredisplayedingrey.Usethe
cursorandselectindividualmessages
withtheSelectbuttonontheOperating
Panel.Formoreinformation,see
’Cursor’eldonpage86andMessage
Baronpage142.
Menubuttons
•Ack(knowledge):Pressthisbuttonto
acknowledgetheselectedmessage
•Delete:Pressthisbuttontodeletethe
selectedmessage.
•Close:Clickthisbuttontoclosethe
menu.
•Help:Clicktoopentheon-linehelp
system.
