SimradSH90
Messages
Whennecessary,thesonarwillprovideyou(oryourservice
engineer)withoperationalandtechnicalmessages.These
messagesaresortedintofourcategories;
1Warnings
2Operatoralarms
3Systemalarms
4Errors
Inordertoaccessthemessages,theMessageBarmustbeenabled.
Thisfunctioncanbesettoactivateitselfwhennecessary.The
MessageBarislocatedatthebottomofthedisplay,anditcontains
fourbuttons,oneforeachcategoryofmessages.Thesebuttons
giveanoverviewofthenumberofunreadmessagescurrentlyin
thesystem.Eachofthefourbuttonsgivesaccesstoadialog
whereeachmessagecanberead,acknowledgedanddeleted.
Whennomessagesarepresent,thefourbuttonsaregrey.When
oneormoreunreadmessagesexists,theWarningandOperational
Alarmbuttonsareyellow,whiletheSystemAlarmandError
buttonsarered.
Figure32TheMessageBarbuttons
Formoreinformation,seeMessageBaronpage142
