Menudescriptions
•DataSource:Thisbuttonisusedtoselectthebearingsource
oftheverticalviews.IfyouselectAudio,theverticalslicewill
followthetrainableaudiochannel.IfyouselectIndicator,the
bearingoftheverticalslicecanbeadjustedindependentofthe
audiochannel.(►DataSourceonpage128)
•DirectionIndicator:Thisfeatureallowsyoutotrainthe
verticalslicesindependentoftheaudiochannel.Thedirection
indicatorisshowninthehorizontalpresentationasayellow
dottedline.(►DirectionIndicatoronpage131)
CatchViewmenu
Menudescription
TheCatchViewmenuisactivatedby
pressingtheViewbuttonontheOperating
Panel(orthem
i d d l e mousebutton)while
thecursorislocatedintheCatchview,
andthenselectingViewmenuintheView
pop-up.
Thismenuprovidescontrolofselected
parametersrelatedtothecurrentdata
displayedintheCatchview.Notethat
theCatchviewisonlyavailableinthe
270º/Vertical,TrueMotion/Verticaland
Bowup/Verticaldisplaymodes,andyou
mayneedtohidethemenutoseeit.
•TheClosebuttonclosesthismenu.
•TheHelpbuttonopenstheon-line
help.
Menubuttons
•Range:Clickthisbuttontoselectthehorizontalrange.
(►Range(CatchView)onpage152)
