Installation Guide

Grand Rapids, MI
800.253.1561
simplyputorganizers.com ©2017 Knape & Vogt. All rights reserved. Knape & Vogt
®
reserves the right to change specifications without notice. 310581/0917
Install the rear wire cage first. Fully extend
sliding members out of the cabinet. Place
the slotted holes on the cage onto the tabs
on the left hand sliding member. (2A) Rest
the cage on top of the clip retainers on the
right hand sliding member, but, DO NOT
PUSH DOWN. Close unit so that the wire
cage is completely inside of the cabinet.
Now, push down firmly on the right side of
the wire cage, until it is fully seated into the
clip retainers. (2B) Repeat the same process
for the front wire cage. (Again, do not push
the cage into the clip retainers until the cage
is completely inside the cabinet.)
Install cage locking clips into front and
rear cages on the right hand slides only by
placing the tabs on the top of the clip into
the openings in the slide. Then push the top
of the clip until it snaps into place. (3)
Clip handle onto front of cage. (4)
2
3
4
Tab
2a
Clip Retainer
2b
4
Push Top until it snaps
3
