CAUTION: When PHI battery quantities change, the capacity & charge/discharge current settings
must be reassessed. Failure to do so will void the Warranty.
4.4 – FLEXnet DC Settings
Table 3.0 - Settings for SimpliPhi PHI 3.8 kWh 48V Battery w/Outback FLEXnet DC
FLEXnet DC Settings
10k Cycles
(80% DoD)
5k Cycles
(90% DoD)
3.5k Cycles
(100% DoD)
FNDC Battery Ah
1
151Ah / 75Ah
FNDC Charged Voltage (V)
27.0 / 54.0
27.0 / 54.0
27.8 / 55.6
FNDC Charged Return Amps
1
8A / 4A
FNDC Battery Charge Factor
98%
FNDC Relay Invert Logic
No
FNDC Relay Voltage High/Low
High = 26.5/53, Low = 28.8/49.6
FNDC Relay SOC High/Low
SOC High = 0%, SOC Low = 0%
FNDC Relay Delay
High = 1, Low = 0
Notes:
• 1. Per PHI 3.8 kWh battery – These settings are calculated by multiplying the nominal per battery value
times the # of batteries. Refer to Charge Controller Bank Sizing under the “Battery Bank Sizing” section.
• Levels are typical @ 25C and may need adjusting at temperature extremes.
• When performing rapid deep charge/discharge cycles the battery should be allowed to "rest" 15 minutes in
between.
CAUTION: When PHI battery quantities change, the capacity & charge/discharge current settings
must be reassessed. Failure to do so will void the Warranty.
While the FLEXnet DC Battery Monitor provides State of Charge (SoC) readings, the PHI batteries’ most
accurate SoC gauge is according to Voltage:
Table 4.0 - SimpliPhi PHI Battery SoC vs. Voltage
SOC
24V
48V
100%
> 26.25 VDC
> 52.5 VDC
95%
25.9 VDC
51.7 VDC
90%
25.8 VDC
51.65 VDC
75%
25.7 VDC
51.4 VDC
50%
25.5 VDC
51.0 VDC
20%
25.1 VDC
50.2 VDC
10%
24.8 VDC
49.5 VDC
0%
24.0 VDC
48.0 VDC
