SimpliPhi 2.7kWh Lo-Profile Battery Specifications

PHI 2.7
TM
LO-PROFILE 24V 48V
DC Voltages – Nominal
25.6 51.2
Amp Hours
105 52
Rated kWh Capacity @ C/2
2.7 kWh
Max Discharge Current
60 Amps (10 mins)
Max Contin. Charge Current 45
Amps 26 Amps
DC Voltage Range
1
20 to 28.8 40 to 57.6
Depth of Discharge
1
up to 100%
Operating Effi ciency
98%
Operating Temp
1
-4° to 140°F (-20° to 60°C)
Charge Temp
1
32° to 120°F (0° to 49°C)
Self-Discharge Rate
<1% loss per month
Cycle Life
10,000+
Memory Effect
None
Warranty Period
Dimensions
SIMPLIPHI YOUR POWER WITH
PHI 2.7
TM
LO-PROFI
L
E BATTERY
10 Years
17.5 x 14 x 5 inches / 0.71 cu ft
(44.45 x 35.56 x 12.7 cm / 0.020 m3)
• Meets transport safety weight requirements: Less than 35 kg including packaging
• UN 3480, Lithium ion batteries, 9, II
• UL and CE listed, UN/DOT and RoHS compliant components
• Designed and built in California, USA
420 Bryant Circle | Ojai, CA 93023, USA | [phone] | SimpliPhiPower.com
Power. On Your Terms.™
© 2018 SIMPLIPHI POWER, INC. REV061918
• Anderson 200 Amp PowerMod Quick Connect
• 24V and 48V LFP batteries with proprietary architecture and Battery Management
System (BMS)—do not require ventilation, cooling or thermal regulation
• Compatible with all industry standard inverter/charger controllers
• Drop in replacement for lead acid
• LFP is the safest, most environmentally benign Lithium Ion chemistry available—no cobalt, risk of
thermal runaway or fi re
• No AC or toxic liquid cooling—negligible parasitic drain—long cycle life
• Non-toxic and non-hazardous recyclable materials
THE
The PHI 2.7
TM
kWh 60 Amp deep-cycle
Lithium Ferro Phosphate (LFP) battery is
optimized with proprietary cell architecture,
power electronics, BMS and manufacturing
methods. It is modular, lightweight and scal-
able for installations that range from kWh to
MWh. Provides power security and seamless
integration of renewable and traditional
sources of energy in conjunction with or
independent of the grid: net zero, peak shav-
ing, emergency back-up, portable & mobile.
• All specifications listed are typical/nominal and subject to change without notice.
• 1. Max operating conditions. Refer to Warranty for recommended conditions.
Weight
61 lbs (27.7 kg)
Max Contin. Disch. Current 45
Amps 26 Amps
