12. STANDBY BATTERY REQUIREMENTS
The Following Table shows the Quiescent, Fault & alarm currents of the main parts of a SIMPLICITY
Fire Alarm System
Device
Product Code
I
q
(mA)
I
flt
(mA)
I
alm
(mA)
Max
per
Loop
Max
per
System
SIMPLICITY 64 Fire Alarm Panel
SP-64
100 150 200 N/A 1
SIMPLICITY 126 Fire Alarm Panel
SP-126
100 150 200 N/A 1
Fyreye Addressable Ionisation Smoke Detector
FEAI2000
0.6 N/A 2 126 126
Fyreye Addressable Optical Smoke Detector
FEAO2000
0.6 N/A 2 126 126
Fyreye Addressable Heat Detector
FEAH2000
0.6 N/A 2 126 126
Fyreye Addressable High Temperature Heat Detector
FEAHH2000
0.6 N/A 2 126 126
Fyreye Addressable Multi-point Detector
FEAOH2000
0.6 N/A 2 126 126
Fyreye Addressable Carbon Monoxide Detector
FEAHH2000
0.6 N/A 2 126 126
Fyreye Addressable Sounder Base
FEA-SB
0 N/a 3* 126 126
Zeta Addressable Call Point
ZT-MCP/AD
0.4 N/a 13 126 126
Zeta Weatherproof Addressable Call Point
ZT-MCP/AD/WP
0.4 N/a 13 126 126
Zeta Input Unit
ZIU
2 2 10 126 126
Zeta Input Output Unit
ZIOU
2 2 10 16 16
Zeta Sounder Control Module
ZSCC
2 2 10 16 16
Zone Monitor Unit
ZT-ZM
2 2 50 126 126
Fyreye Addressable Beam Detector (5-50m)
ZTA-FR50
t.b.c. t.b.c. t.b.c. t.b.c. t.b.c.
Fyreye Addressable Beam Detector (50-100m)
ZTA-FR100
t.b.c. t.b.c. t.b.c. t.b.c. t.b.c.
Fyreye Plus Addressable Aspiration Detector
FE+50/AD
t.b.c. t.b.c. t.b.c. t.b.c. t.b.c.
Zeta Addressable Maxitone Sounder
ZAMT
1.5 N/a 9 32 32
Zeta Addressable Miditone Sounder
ZAMD
1.5 N/a 9 32 32
Zeta Addressable Securetone Sounder
ZAST
1.5 N/a 9 32 32
Zeta Addressable Remote LED Indicator
ZTA/LE2
1.5 N/a 10 32 32
Zeta Conventional Maxitone Sounder
ZMT/8
0 N/a 15 N/a N/a
Zeta Conventional Miditone Sounder
ZMD/8
0 N/a 15 N/a N/a
Zeta Conventional Securetone Sounder
ZST/8
0 N/a 15 N/a N/a
Zeta Conventional Megatone Sounder
ZIDC
0 N/a 200 N/a N/a
Zeta Conventional Flasher
ZFL2RR
0 N/a 90 N/a N/a
Zeta Conventional Sounder Flasher
ZLT/8RR
0 N/a 110 N/a N/a
Zeta Conventional 6” Bells
ZTB6B/24
0 N/a 25 N/a N/a
Zeta Conventional 8” Bells
ZTB8B
0 N/a 35 N/a N/a
Fyreye Conventional Optical Detector
FEO2000
0.06 N/a 25 N/a N/a
Fyreye Conventional Heat Detector (A1R)
FEHR2000
0.04 N/a 25 N/a N/a
Fyreye Conventional Heat Detector (CS)
FEFH2000
0.04 N/a 25 N/a N/a
* 3 mA Version of sounder base due May 2004. Any supplied before this date will take up to 9 mA.
